# Architecture

YouDesign Freelucy is a **scoped ServiceNow application** that runs entirely inside your ServiceNow instance. It introduces no custom tables, requires no integrations, and reads only the tables your administrators authorize through cross-scope privileges.

{% hint style="warning" %}
🖼️ **Screenshot needed — `v26-architecture-diagram.png`** The Freelucy v26 application architecture diagram: the scoped app running on the Now Platform, reading core CMDB tables, with the multi-view editor on top.
{% endhint %}

***

## What this means in practice

* **100% on ServiceNow.** Freelucy runs natively. There is no external service, no integration to configure, and no data leaving your instance.
* **No custom tables.** Freelucy uses core ServiceNow constructs, such as `cmdb_rel_ci`, `cmdb_rel_type`, scoped roles, and cross-scope privileges. Nothing new is introduced into your data model.
* **No additional licenses.** Because no custom tables are added, no additional ServiceNow end-user licenses are required to use Freelucy.
* **Governed access.** Administrators control which tables Freelucy can read, through cross-scope privileges, and which class pairs users can connect, through suggested relationships. Users only see what your governance allows.
* **Built on Now™ certified.** Freelucy holds ServiceNow's highest technical designation for partner applications, meaning it has been designed and tested for fast, agile, resilient, and secure interaction on the Now Platform.

***

## How the editor is built

Freelucy presents one record through three views, and they all share the same editing state.

* **One editing model, many views.** Classic, Flow, and List are interchangeable views over the same record. Your staged changes live in one shared place, so switching views never loses work.
* **Stage then commit.** Edits are held as pending changes and written to ServiceNow only when you commit, as a single batch.
* **Rule-driven.** A relationship-rule resolver decides which sides and relationship types are valid for any given pair of records, so every view offers only the relationships your metamodel permits.

***

## What's next

* See [Configuration overview](/freelucy/configuration/configuration.md) for the administrator setup that activates this architecture for your users.
* See the [Glossary](/freelucy/reference/glossary.md) for the terms used throughout this documentation.


---
